Imagine for a moment you are building an autonomous robot that can collect litter on the ground. The robot needs to detect the litter to collect them and you – as a machine learning engineer – should build a litter detection system. This project, like most real-life computer vision problems, is challenging due to the variety of objects and backgrounds. In this technical tutorial, we will show you how Encord Active can help you in this process.
We will use Encord Active to analyze the dataset, the labels, and the model predictions. In the end, you will be know how to build better computer vision model with a data-centric approach.
Okay! Lets go.
For the tutorial we will use the open-source TACO dataset. The dataset repository contains a official dataset with 1500 images and 4784 annotations and an unofficial dataset with 3736 images and 8419 annotations. Both datasets contain various large and small litter objects on different backgrounds such as streets, parks, and beaches. The dataset contains 60 categories. of litter.
Example images from the official dataset:
So, let’s download the dataset from the official website by following the instructions. Currently, there are two datasets, namely, TACO-Official and TACO-Unofficial.
In this project, we will use the official dataset as a validation set and the unofficial dataset as a training set.
To directly create a conda virtual environment including all packages, check the readme of the project.
You can import a COCO project to Encord Active with a single line command:
encord-active import project --coco -i ./images_folder -a ./annotations.json
We will run the above command twice (once for each dataset). The flow might take a while depending on the performance of your machine, so sit back and enjoy some sweet tunes.
This command will create a local Encord Active project and pre-compute all your quality metrics.
Quality metrics are additional parameterizations added onto your data, labels, and models; they are ways of indexing your data, labels, and models in semantically interesting and relevant ways. In Encord Active, there are different pre-computed metrics that you can use in your projects. You can also write your own custom metrics.
Once the project is imported you will have a local Encord Active project and we can start to understand and analyse the dataset.
First, let’s analyze the official dataset. To start the Encord Active application, we run the following command for the official dataset:
# from the projects root encord-active visualise OR # from anywhere encord-active visualise --target /path/to/project/root
Your browser will open a new window with Encord Active.
Now let’s analyze the dataset. First, we navigate to the Data Quality → Explorer tab and check the distribution of samples with respect to different image-level metrics.
Area: The Images in the dataset are fairly large, where the median image size is around 8 megapixels (roughly 4000x2000). So, they need to be processed properly before the training. Otherwise reading them from the disk will create a serious bottleneck in the data loader. In addition, we can see on the plot below that there are a few outliers of very large images and very small images. Those can be excluded from the dataset.
Aspect Ratio: Most images have an aspect ratio of around 0.8, which brings to mind that they are mostly taken with mobile phone cameras (in a vertical direction) which may create a potential bias when going to production.
Brightness: Most images are taken during the daytime, and there are a few images taken during the evening (when it is a bit darker). So, this will potentially affect the performance of the model when it is run in environments where it is darker.
Next, we will analyze the label quality. Go to the Label Quality → Explorer tab and analyze the object-level metrics here:
Class distribution: In total, there are 5038 annotations for 59 classes. It is clear that there is a high class imbalance with some classes having fewer than 10 annotations, and some more than 500.
Frame Object Density: In most of the images, objects only cover a small part of the image, which means annotation sizes are small compared to the image size. Thus it is important we choose a model accordingly (AKA avoid using models that have problems with small objects).
Object Annotation Quality: This metric gives a score for each object according to its closest neighbors in the embedding space. If the closest neighbors have a different label, the quality of the annotation will be low. We see that there are many samples with low object quality scores. This may mean several things: for example, different object classes may be semantically very close to each other, which makes them closer in the embedding space, or there might be annotation errors. These should be analyzed, cleaned, and fixed before model training.
Another interesting point is that when the average object annotation quality scores are compared between the unofficial and official datasets (mean score under Annotator statistics), there is a huge difference (0.195 vs. 0.336). Average scores show that the unofficial dataset has lower annotation quality, so a review of the annotations should be performed before the training.
Distribution of the object annotation quality for the official dataset
Distribution of the object annotation quality for the unofficial dataset
Object Area - Relative: Most of the objects are very small compared to the image. So, for this problem, images can be tiled or frameworks like SAHI can be used.
Based on the preliminary analysis we can draw following conclusions:
Next let us start to prepare the data for training :)
First, let’s filter and export the data and annotations to create COCO annotations. Although the datasets already contain COCO annotations, we want to generate a new COCO file where attributes are compatible with Encord Active so when we import our predictions to Encord Active, images can be matched.
In every batch, images should be loaded from the disk, however, as we concluded above, they are too large to be loaded efficiently. Therefore, to avoid creating any bottlenecks in our pipeline, we downscale them before starting the training. An example of this can be seen in the project folder utils/downscale_dataset.py. We have scaled all the images to 1024x1024. Loaded images will also be scaled internally by our model before feeding into the model.
For training, we chose to train Mask-RCNN architecture in the Torchvision package. Further, we used PyTorch to train it and Wandb to log the performance metrics.
We have implemented EncordMaskRCNNDataset class, which can be used with any COCO dataset generated from the Encord Active so it can be used not just for this project but any project generated from the Encord Active. It transforms the input and output into the format that MaskRCNN model wants:
class EncordMaskRCNNDataset(torchvision.datasets.CocoDetection): def __init__(self, img_folder, ann_file, transforms=None): super().__init__(img_folder, ann_file) self._transforms = transforms def __getitem__(self, idx): img, target = super().__getitem__(idx) img_metadata = self.coco.loadImgs(self.ids[idx]) image_id = self.ids[idx] img_width, img_height = img.size boxes, labels, area, iscrowd = [], [], [], [] for target_item in target: boxes.append( [ target_item["bbox"][0], target_item["bbox"][1], target_item["bbox"][0] + target_item["bbox"][2], target_item["bbox"][1] + target_item["bbox"][3], ] ) labels.append(target_item["category_id"]) area.append(target_item["bbox"][2] * target_item["bbox"][3]) iscrowd.append(target_item["iscrowd"]) segmentations = [obj["segmentation"] for obj in target] masks = convert_coco_poly_to_mask(segmentations, img_height, img_width) processed_target = {} processed_target["boxes"] = torch.as_tensor(boxes, dtype=torch.float32) processed_target["labels"] = torch.as_tensor(labels, dtype=torch.int64) processed_target["masks"] = masks processed_target["image_id"] = torch.tensor([image_id]) processed_target["area"] = torch.tensor(area) processed_target["iscrowd"] = torch.as_tensor(iscrowd, dtype=torch.int64) if self._transforms is not None: img, processed_target = self._transforms(img, processed_target) return img, processed_target, img_metadata def __len__(self): return len(self.ids)
After defining the Torchvision dataset we create a dataset for the data loader:
dataset = EncordMaskRCNNDataset( img_folder=params.data.train_data_folder, ann_file=params.data.train_ann, transforms=get_transform(train=True), ) data_loader = torch.utils.data.DataLoader( dataset, batch_size=params.train.batch_size, shuffle=True, num_workers=params.train.num_worker, collate_fn=collate_fn, )
The training loop is very straightforward. For each epoch, we train the model on the training set. Once the training is finished for that epoch, we measure the performance on training and validation sets and log the results. To make this training more elegant we have:
for epoch in range(params.train.max_epoch): print(f"epoch: {epoch}") train_one_epoch(model, device, data_loader, optimizer, log_freq=10) if epoch % params.logging.performance_tracking_interval == 0: train_map = evaluate(model, device, data_loader, train_map_metric) val_map = evaluate(model, device, data_loader_validation, val_map_metric) scheduler.step(val_map["map"]) if params.logging.wandb_enabled: train_map_logs = {f"train/{k}": v.item() for k, v in train_map.items()} val_map_logs = {f"val/{k}": v.item() for k, v in val_map.items()} wandb.log( { "epoch": epoch + 1, "lr": optimizer.param_groups[0]["lr"], **train_map_logs, **val_map_logs, } ) val_map_average = val_map["map"].cpu().item() if val_map_average > best_map * (1 + 0.0001): early_stop_counter = 0 best_map = val_map_average print("overwriting the best model!") if params.logging.wandb_enabled: wandb.run.summary["best map"] = best_map torch.save( model.state_dict(), os.path.join(wandb.run.dir, "best_maskrcnn.ckpt"), ) else: torch.save(model.state_dict(), "weights/best_maskrcnn.ckpt") else: early_stop_counter += 1 if early_stop_counter >= params.train.early_stopping_thresh: print("Early stopping at: " + str(epoch)) break print("Training finished")
We have provided the supportive and utility functions and modules inside the project folder.
Before diving into the full model training, let’s check if the training pipeline works as expected. To check that, we run the training on a few samples and expect the model to overfit into those samples. This is a common trick to check if the training pipeline works from end to end as expected.
We have prepared a configuration file (config.ini) to set the training scripts. Once all the paths and training parameters are set correctly, we can start training:
(encord-maskrcnn) > python train.py
Model checkpoints are saved to the local wandb log folder so that we can use it later for inference.
Here is a sample log result for mAP and mAP@50 for both training and validation sets.
There are a few ways to import predictions into Encord Active, for a more detailed explanation please check here.
In this tutorial we will prepare a pickle file consisting of Encord Active Prediction objects, so they can be understood by the Encord Active. First, we need to locate the wandb folder to get the path of the model checkpoint. Every wandb experiment has a unique ID, which can be checked from the overview tab of the experiment on the wandb platform. Once you learned the wandb experiment ID, local checkpoint should be somewhere like this:
/path/to/project/wandb/run-[date_time]_[wandb_id]/files/best_maskrcnn.ckpt
Once you set up the inference section of the config.ini file, you can generate Encord Active predictions.
Here is the main loop to generate the pickle file:
model.eval() with torch.no_grad(): for img, _, img_metadata in tqdm( dataset_validation, desc="Generating Encord Predictions" ): prediction = model([img.to(device)]) scores_filter = prediction[0]["scores"] > confidence_threshold masks = prediction[0]["masks"][scores_filter].detach().cpu().numpy() labels = prediction[0]["labels"][scores_filter].detach().cpu().numpy() scores = prediction[0]["scores"][scores_filter].detach().cpu().numpy() for ma, la, sc in zip(masks, labels, scores): contours, hierarchy = cv2.findContours( (ma[0] > 0.5).astype(np.uint8), cv2.RETR_TREE, cv2.CHAIN_APPROX_NONE ) for contour in contours: contour = contour.reshape(contour.shape[0], 2) / np.array( [[ma.shape[2], ma.shape[1]]] ) prediction = Prediction( data_hash=img_metadata[0]["data_hash"], class_id=encord_ontology["objects"][la.item() - 1][ "featureNodeHash" ], confidence=sc.item(), format=Format.POLYGON, data=contour, ) predictions_to_store.append(prediction) with open( os.path.join(validation_data_folder, f"predictions_{wandb_id}.pkl"), "wb" ) as f: pickle.dump(predictions_to_store, f)
Once we have the pickle file, we run the following command to import predictions:
encord-active import predictions /path/to/predictions.pkl
Lastly, we refresh the Encord Active browser.
With a freshly trained model, we’re ready to gather some insights. Encord Active automatically matches your ground-truth labels and predictions and presents valuable information regarding the performance of your model. For example:
First we evaluate the model on a high-level.
As explained previously we used the unofficial dataset for the training and official dataset for validation.
For the entire dataset we achieved a mAP @ 0.5 IOU at 0.041.
The mAP is very low. This means that the model is having difficulty detecting litters. We have also trained a model where both training and validation sets are from the official dataset, and the results were around 0.11, which is comparable with the reported results in the literature. This result also shows how difficult our task is.
First we want to investigate what quality metrics impact model performance. High importance for a metric implies that a change in that quantity would strongly affect model performance:
Hmm... object area, frame object density, and object count are most important metrics for the model performance. We should investigate that.
Not surprisingly, among the best performing object are larger and distinct object such as cans and bottles.
Worst performing objects are the ones which do not have a clear definition: other plastic, other cartoon, unlabeled litter.
Next we, go dive into the model performance by metric and examine performance with respect to different metrics. Here are some insights we got from there:
Let’s examine a few true positive:
The model segments some objects very well. In this tab, we can rank all true positives according to a metric that we want. For example, if we want to visualize correctly segmented objects in small images, we can select the area metric on the top bar.
Let’s examine a few false positives:
We see some interesting patterns here. The model’s segmentation for the objects are quite good, however, they are regarded as false positives. This may mean two things: 1) the model is confused about the object class or 2) there is a missing annotation. After inspecting the ground truth labels, we found that there are some classes which are confused with each other (e.g., garbage bag vs. single use carrier bag, glass bottle vs. other plastic bottle).
Examples from picture below
If we detect frequently confused objects, we can provide more data for these object classes or we can add specific post-processing steps to our inference pipeline, which will eventually increase our overall performance. These points are all very valuable to know when building our litter detection system since they show us areas we need improvement in our computer vision pipeline.
With the help of the Encord Active, we now have a better understanding of what we have in our hands and we:
With the insights we got from Encord Active, we now know what should be prioritized. In the second part of this tutorial, we will utilize the information we obtained here to improve our baseline result with a new and improved dataset.
"I want to get started right away" - You can find Encord Active on Github here.
"Can you show me an example first?" - Check out this Colab Notebook.
"I am new, and want a step-by-step guide" - Try out the getting started tutorial.
If you want to support the project you can help us out by giving a Star on GitHub :)
